Name: B.O.T.C.K- Bolt On TrackBar Correction kit 4r g4&5 / gx460 & 470/ FJ cruiser / Prado 150
Brand: Dr KDSS
Price: 299.0 CAD
Availability: InStock

B.O.T.C.K- Bolt On TrackBar Correction kit 4r g4&5 / gx460 & 470/ FJ cruiser / Prado 150

$299.00

Shipping calculated at checkout.

Free US shipping

In stock, ready to ship
Backordered, shipping soon

Fits: 4th & 5th Gen 4Runner / GX470 & GX460 / FJ Cruiser / Prado 150
(Not for Gen 3)

What It Does

Fixes that sketchy, side-to-side axle swing after a lift.
Brings your track bar (panhard bar) back to a more natural, level position.
Keeps your rig tracking straight, planted, and predictable on-road and off.
Bolt-on design — no welding, no guesswork.

Why It Matters

When you lift your rig, the track bar angle gets steep. That forces the axle to swing left/right instead of moving up/down — making the rear feel unstable.
The B.O.T.C.K. raises the pivot point to flatten that bar and bring your handling back to normal. Simple fix, huge difference.

Shorty vs. Regular – Pick the Right One

How to Pick the Correct B.O.T.C.K. Version

Park on level ground.
Measure from the ground to the center of the frame-side track-bar bolt.
Measure from the ground to the center of the axle-side track-bar bolt.
Subtract the two measurements to find your bolt-height difference:

1.5"–2.99" → Shorty Version (or use the bottom hole on the Standard bracket)
3" or higher → Standard Version (use the top hole)

Planning to lift higher later? Go with the Standard Version — it gives you extra mounting options as your suspension height changes.

Updates You Need to Know

No more flange nuts – now standard hex nuts.
Washer for side bolt no longer needed.
Torque spec: 105 ft-lbs on all bolts with lots of blue Loctite (or a little red). If you send it with and 18v impact you still couldn’t break the bolts. 125lbs is my max torque.
KDSS or non-KDSS? Doesn’t matter. Works with both.

Real Talk

Stop buying parts you don’t need — understand what it does before hitting checkout.
This kit isn’t just stronger than weld-on options — it spreads load evenly across the OEM mount instead of depending on the welds.
Designed for rigs that actually see dirt, not just mall crawlers.

What’s Included

Front bracket
Back bracket
Flag nut
(1x) M14 x 1.5 x 75mm flange head bolt
(2x) M14 x 1.5 x 35mm flange head bolt
(1x) M14 hex nut
All hardware is zinc coated

Fulfillment Time: Please allow 36–48 hours.

UPDATED: (Torque bolts to 105 ft-lb)

20% restock fee ( no exceptions )!!

“Important shipping / insurance info: if you don’t choose more insurance to cover the cost of whatever you are buying and it is lost or damaged to the point where a claim is being made I will only cover $100 worth as that is the amount they only cover! You have been warned “

ATTENTION Canadian customers !! If you chose UPS as your shipping option , there are times where UPS will impose an import fee! I don’t know how they determine the cost but some customers are stating $100-$120 US dollars which is ridiculous! I have no control over it once it leaves me and enters Canada I think it’s a government fee they are charging UPS in which some one has to pay ! You have been warned There’s always DHL option and USPS

Click Here to View Install Guides

We want you to be completely satisfied with your purchase. Please read our return and exchange policy carefully before initiating a request.

Eligibility for Returns

Items must be unused, uninstalled, and in brand-new condition with no signs of attempted installation.
The product must be properly packaged to prevent damage during transit.
Customers must contact us before initiating a return to receive approval and instructions.

Restocking Fee & Return Shipping

A 20% restocking fee applies to all returns, no exceptions.
We will cover the cost of the return shipping label, but the item must be packaged securely to avoid damage.

Exchanges

We do offer exchanges, but the customer is responsible for covering shipping costs both ways (returning the original item and shipping the new item).
The product must be in brand-new, unused condition to qualify for an exchange.

Damaged Returns

If the returned item arrives damaged or improperly packaged, we will send it back to you, and the return will not be processed.

By purchasing from us, you agree to these return and exchange terms. If you have any questions, please contact us before initiating a return or exchange.
