Name: KDSS Drop Spacers ( rear)
Brand: Dr KDSS
Price: 180.0 USD
Availability: OutOfStock

$180.00

Shipping calculated at checkout.

Free US shipping

In stock, ready to ship
Backordered, shipping soon

Fits: 2010-Current 4Runner / GX460 with KDSS

What It Does

Corrects interference between the track bar and rear sway-bar links on lifted KDSS trucks if you introduce extended travel.
Relocates the KDSS sway-bar pivot points for better clearance and geometry.
Designed specifically for KDSS-equipped 4Runner and GX460 platforms.
If you want to run a 285 7017 tire in the spare OEM location

Why You Need It

When you add extended-travel shocks to the rear of a KDSS-equipped rig, the track bar can hit the sway-bar links and stop droop early.
These drop spacers move the sway-bar’s axis down just enough to clear everything, so your shocks can use all their travel.
If you’ve ever noticed your rear end hanging up or “stopping short” when you flex the truck, this is the fix.

Design & Origin

Invented and U.S. patent pending by DRKDSS.
Machined from 6061 billet aluminum with an anodized finish.
Includes all required hardware — sold in pairs.
Over-engineered for real trail abuse, not just parking-lot lifts.

Do You Need Them?

If you’re not sure, do this quick check:

Chock your front wheels.
Jack up the rear by the hitch until the tires are off the ground.
Crawl underneath and inspect the track bar and sway-bar links.

If you see or feel them touching, your suspension is binding — you need these spacers.
If there’s no contact, you’re good without them.

Install Notes

Bolt-on install using supplied hardware.
Torque to 70 - 75 ft-lbs and re-check after first few drives.
Install video coming soon (check the product page).
Compatible only with KDSS-equipped vehicles.

Benefits

✅ Restores full shock travel for smoother articulation. If you introduce long travel
✅ Eliminates track-bar-to-sway-bar interference.
✅ Protects KDSS components from stress or premature wear.
✅ Works perfectly with extended-travel suspension kits.
✅ CNC-machined and anodized for long-term durability.

Real Talk

Sold in pairs with hardware included.
If you can add it to the cart, it’s in stock.
20 % restock fee applies on returns.
Invented, tested, and proven by DRKDSS — not a copy.
Built for people who actually cycle their suspension, not just lift and cruise.

20% restock fee ( no exceptions )!!

“Important shipping / insurance info: if you don’t choose more insurance to cover the cost of whatever you are buying and it is lost or damaged to the point where a claim is being made I will only cover $100 worth as that is the amount they only cover! You have been warned “

ATTENTION Canadian customers !! If you chose UPS as your shipping option , there are times where UPS will impose an import fee! I don’t know how they determine the cost but some customers are stating $100-$120 US dollars which is ridiculous! I have no control over it once it leaves me and enters Canada I think it’s a government fee they are charging UPS in which some one has to pay ! You have been warned There’s always DHL option and USPS
