Regular price$185.00
/
Color

INSTOCK

Can not be combined with front KDSS drop spacer! Designed for 1.5 - 3.5”+ suspension lift on kdss equipped 2010-22 4runner / gx460 / prado that have minimum factory spec Castor or higher  !!  Factory spec castor can only be achieved with an aftermarket upper control arms.  I only recommend TotalChoas !!

Also these are only designed for stock kdss like mounts on lower control arms.


 add OEM Toyota Bushings





( sold as a pair ( driver and passenger side)  made from 4130 chromoly !!

please allow 36 -48 hours to fulfill!

Benefits:
- keeps the sway bar up nice and high away from skid plate
- corrects the bad bushing angle.
- extends the life of bushings.
- easier to re-install when changing bushings( so the ppl who don’t work on their own vehicle won’t be surprised that you have different bolts from being stripped out 😂. It’s common for a technician to not understand the system and force bolts on or off with out proper steps.
- allows full droop when you have extended travel or long travel setup ( total chaos +2 LT for KDSS).
- lightens up the spring rate on the front sway bar.
- creates a more stout floor jack point.

Kdss was never designed to have the suspension raised / lifted.  When you introduce a suspension system that raises the ride height, the bushing(s) at the lower control arm(s) get into a bad angle and the bushing(s) binds up.  This accelerates the wear of the bushing(s) which eventually you will have metal on metal contact with the sway bar and bushing mount.   These KDSS sway bar end adapters correct that bad bushing angle and will extend the life of the bushing for many many 10’s of thousands of miles. Possibly longer.

Inherently, when a suspension or lift kit is added , the shocks allow for a more travel … ie extended travel and or long travel.   As the front suspension is raised or it droops out under the suspension cycle , the front kdss sway bar swings back towards the motor. If you have enough suspension down travel, the hard link not only gets into a bad angle, it also will contact the frame in some cases, putting your down travel to a dead stop as the system can no longer swing back.  The passenger side will run out of down travel because of the fixed-length link.   The driver's side doesn’t because it has a shock that can extend down.  These KDSS bushing adapters push the sway bar forward away from the frame so there’s no contact at full droop.

Factory bushing bracket bottom hooks must be cut off.

15% restock fee for returns
